Product Description
Brand new, genuine Garmin Fusion® XS Series Marine Speakers. This is a factory original equipment item, not aftermarket.
6.5" 200-Watt Sports Marine Speakers (Pair) with RGB LED Lighting.
Enjoy high-performance acoustics, enhanced protection from the environment and multicolor RGB LED lighting all at a midrange price point with the XS Series speakers from Fusion.
| General | |
|---|---|
| Physical dimensions (Diameter x Depth) | 7.7" Classic: 7.72" x 3.70" (196 x 94 mm) 7.7" Sports: 7.72" x 3.82" (196 x 97 mm) 6.5" Classic: 6.97" x 3.19" (177 x 81 mm) 6.5" Sports: 6.97" x 3.27" (177 x 83 mm) 4" Classic: 5.31" x 2.68" (135 x 68 mm) |
| Water and dust rating | IP65 |
| Configuration | Coaxial |
| Speaker size | XS-F77CWB/XS-F77SPGW/XS-FL77SPGW: 7.7" XS-F65CWB/XS-F65SPGW/XS-FL65SPGW: 6.5" XS-F40CWB: 4" |
| Peak power (Watts) | 7.7" Speaker: 240 W 6.5" Speaker: 200 W 4" Speaker: 120 W |
| RMS power (Watts) | 7.7" Speaker: 60 W 6.5" Speaker: 50 W 4" Speaker: 30 W |
| Sensitivity (1 W / 1 m) | 7.7" Speaker: 92 dB 6.5" Speaker: 91 dB 4" Speaker: 87 dB |
| Frequency response | 7.7" Speaker: 70 Hz-18 kHz 6.5" Speaker: 80 Hz-18 kHz 4" Speaker: 100 Hz-18 kHz |
| Nominal impedance | 4 ohms |
| Recommended amplifier power (RMS) | 7.7" Speaker: 25-200 W/Ch 6.5" Speaker: 20-150 W/Ch 4" Speaker: 15-80 W/Ch |
| LED lighting | yes (RGB; XS-FL77SPGW and XS-FL65SPGW only) |
| LED Supply Voltage | 10.8-16 VDC (XS-FL77SPGW and XS-FL65SPGW only) |
| LED load current @ 14.4 VDC | 150 mA (XS-FL77SPGW and XS-FL65SPGW only) |
| Operating temperature range | 32° to 122° F (0° to 50° C) |
| Voice coil diameter | 7.7": 1.18" 6.5": 1.18" 4": 1" |
| Cone material | 7.7" / 6.5": Polypropylene cone with cloth surround 4": Polypropylene cone with rubber surround |
| Tweeter type | Aluminum dome |
| Compass-safe distance | 7.7": 157.5" (400 cm) 6.5": 122" (310 cm) 4": 100.5" (255 cm) |
| Warranty | 3 years |
| Mounting Dimensions | |
|---|---|
| Mounting diameter clearance | 7.7": 6.38" (162 mm) 6.5": 5.31" (135 mm) 4": 3.90" (99 mm) |
| Mounting depth clearance | 7.7": 3.03" (77 mm) 6.5": 2.64" (67 mm) 4": 2.13" (54 mm) |
| Optimum Enclosure Recommendations | |
|---|---|
| Sealed enclosure volume1 | 7.7": 0.35 cubic ft (10 L) 6.5": 0.28 cubic ft (8 L) 4": 0.14 cubic ft (4 L) |
- Experience multicolor RGB LED lighting to brighten up your boating experience. The injection-molded polypropylene cone provides clean, clear audio reproduction.
- The aluminum dome tweeter provides a smooth upper frequency response and increased efficiency.
- With an increase in real power, the voice coil provides a high-quality sound experience.
- The speakers are available in 4”, 6.5” and 7.7” designs with both classic and sports style grilles.
- Engineered to last season after season, the speakers include a 3-year warranty.
SKU# 010-02196-20
Items included in this kit:
4" 120-watt Classic Marine Speaker:
- One pair of XS-F40CWB speakers
- 12 Phillips stainless steel mounting screws (3.5 mm x 25.4 mm (6 gauge x 1”))
- Speaker grilles (1 pair classic white/1 pair classic black)
- Documentation
6.5" 200-watt Classic Marine Speaker:
- One pair of XS-F65CWB speakers
- 12 Phillips stainless steel mounting screws (4.2 mm x 25.4 mm (8 gauge x 1”))
- Speaker grilles (1 pair classic white/1 pair classic black)
- Documentation
6.5" 200-watt Sports Marine Speaker:
- One pair of XS-F65SPGW speakers
- 12 Phillips stainless steel mounting screws (4.2 mm x 25.4 mm (8 gauge x 1”))
- Speaker grilles (1 pair sports gray/ 1 pair sports white)
- Documentation
6.5" 200-watt Sports Marine Speaker with RGB LED Lighting:
- One pair of XS-FL65SPGW speakers
- 12 Phillips stainless steel mounting screws (4.2 mm x 25.4 mm (8 gauge x 1”))
- Speaker grilles (1 pair sports gray/1 pair sports white)
- Documentation
7.7" 240-watt Classic Marine Speaker:
- One pair of XS-F77CWB speakers
- 12 Phillips stainless steel mounting screws (4.2 mm x 25.4 mm (8 gauge x 1”))
- Speaker grilles (1 pair classic white/ 1 pair classic black)
- Documentation
7.7" 240-watt Sports Marine Speaker:
- One pair of XS-F77SPGW speakers
- 12 Phillips stainless steel mounting screws (4.2 mm x 25.4 mm (8 gauge x 1”))
- Speaker grilles (1 pair sports gray/ 1 pair sports white)
- Documentation
7.7" 240-watt Sports Marine Speaker with RGB LED Lighting:
- One pair of XS-FL77SPGW speakers
- 12 Phillips stainless steel mounting screws (4.2 mm x 25.4 mm (8 gauge x 1”))
- Speaker grilles (1 pair sports gray/1 pair sports white)
- Documentation
Fits:
| Description: |
|---|
| Fusion® AM Series Marine Amplifiers |
| Fusion® Apollo™ MS-RA670 Marine Stereo |
| Fusion® Apollo™ MS-RA770 Marine Stereo |
| Fusion® Apollo™ MS-SRX400 Marine Zone Stereo |
| Fusion® Apollo™ MS-WB670 Marine Hideaway Stereo |
| Fusion® MS-BB100 Black Box |
| Fusion® MS-RA210 Marine Stereo |
| Fusion® MS-RA60 Marine Stereo |
| Fusion® RA70 Series Marine Stereos |
| Fusion® Signature Series Marine Amplifiers |
Product Videos
Custom Field
California Prop 65 Click here for information
Availability Description Item will be ordered direct from the manufacturer and generally ships within 5-10 business days. If ordered with any other item(s), fulfillment will not occur until received.
Ship Method **Special Order Item: Item(s) eligible for FREE Ground shipping, with order value over $99. Orders under $99 receive Economy shipping with a $5.99 fee. Faster shipping rates are not available.
Size 6.5"
Available In Stock Quantity 0 Stock On Hand
