Product Description
Brand new, genuine Garmin GPSMAP® 923xsv SideVü, ClearVü and Traditional CHIRP Sonar with Worldwide Basemap. This is a factory original equipment item, not aftermarket.
SPECS
| General | |
|---|---|
| DIMENSION | 9.2" x 6.4" x 3" (23.3 x 16.2 x 7.6 cm) |
| TOUCHSCREEN | Yes |
| DISPLAY SIZE | 7.8" x 4.4"; 9.0" diagonal (19.9 cm x 11.2 cm; 22.9 cm diagonal) |
| DISPLAY RESOLUTION | 1280 x 720 pixels |
| DISPLAY TYPE | WXGA |
| WEIGHT | 3.6 lbs (1.6 kg) |
| WATERPROOF | IPX7 |
| MOUNTING OPTIONS | Bail, flush or flat (Garmin does not offer any hardware or accessories for a flat-mount installation. Professional tools and knowledge is required.) |
| Maps & Memory | |
|---|---|
| ACCEPTS DATA CARDS | 2 microSD cards (back of unit) |
| WAYPOINTS | 5000 |
| TRACK POINTS | 50,000 |
| TRACKS | 50 saved tracks |
| NAVIGATION ROUTES | 100 |
| Sensors | |
|---|---|
| HAS BUILT-IN RECEIVER | Yes |
| RECEIVER | 10 Hz |
| NMEA 2000 COMPATIBLE | Yes |
| NMEA 0183 COMPATIBLE | Yes |
| GPS | Yes |
| GLONASS | Yes |
| GALILEO | Yes |
| SUPPORTS WAAS | Yes |
| Built-in Maps | |
|---|---|
| BUILT-IN AUTO GUIDANCE | Yes |
| BLUECHART (COASTAL) | Yes |
| LAKEVU (INLAND) | Yes |
| TIDE TABLES | Yes |
| Optional Map Support | |
|---|---|
| BLUECHART G3 | Yes |
| BLUECHART G3 VISION | Yes |
| LAKEVÜ G3 | Yes |
| LAKEVÜ G3 ULTRA | Yes |
| GARMIN NAVIONICS+™ | Yes |
| GARMIN NAVIONICS VISION+™ | Yes |
| TOPO | Yes |
| STANDARD MAPPING | Yes |
| GARMIN QUICKDRAW CONTOURS | Yes |
| RASTER CHART SUPPORT | Yes |
| Chartplotter Features | |
|---|---|
| SMART MODE COMPATIBLE | Yes |
| AIS | Yes |
| DSC | Yes |
| SUPPORTS FUSION-LINK™ COMPATIBLE RADIOS | Yes |
| GSD BLACK BOX SONAR SUPPORT | Yes |
| GCV BLACK BOX SONAR SUPPORT | Yes |
| ACTIVECAPTAIN® COMPATIBLE | Yes |
| GRID (GARMIN REMOTE INPUT DEVICE) COMPATIBLE | Yes |
| WIRELESS REMOTE COMPATIBLE | Yes |
| SAILING FEATURES | Yes |
| SPOKEN AUDIO ALERTS | Yes |
| ONEHELM SUPPORT | Yes |
| Electrical Features | |
|---|---|
| POWER INPUT | 10 to 32 Vdc |
| TYPICAL CURRENT DRAW AT 12 VDC | 1.37 A |
| MAXIMUM CURRENT DRAW AT 12 VDC | 3.20 A |
| MAXIMUM POWER USAGE AT 10 VDC | 40.2W |
| Sonar Features & Specifications | |
|---|---|
| DISPLAYS SONAR | Yes |
| POWER OUTPUT | 1 kW |
| TRADITIONAL SONAR (DUAL FREQUENCY/BEAM) | built-in (single channel CHIRP, 70/83/200 kHz, L, M, H CHIRP) |
| CLEARVÜ | built-in 260/455/800/1000/1200 kHz |
| SIDEVÜ | built-in 260/455/800/1000/1200 kHz |
| PANOPTIX™ SONAR | Yes |
| LIVESCOPE | Yes |
| Connections | |
|---|---|
| NMEA 2000® PORTS | 1 |
| CONNECTIONS NMEA0183 INPUT PORTS | 1 |
| NMEA 0183 INPUT (TX) PORTS | 1 |
| VIDEO INPUT PORTS | 1 (BNC composite) |
| J1939 PORTS | 1 |
| GARMIN MARINE NETWORK PORTS | 1 |
| 12-PIN TRANSDUCER PORTS | 1 |
| USB PORTS | Yes |
| BNC EXTERNAL GPS ANTENNA PORT | Yes |
| BLUETOOTH® PAIRING | Yes |
| ANT+ (CONNECTIVITY) | Yes |
| GARMIN WI-FI NETWORK (LOCAL CONNECTION) | Yes |
- Sold Each
SKU# 010-02366-02
Items included in this kit:
- GPSMAP 943xsv chartplotter
- microSD™ card preinstalled
- Power cable
- NMEA 2000® T-connector
- NMEA 2000 drop cable (2 meters)
- 8-pin transducer to 12-pin sounder adapter cable
- Bail mount kit with knobs
- Flush mount kit with gasket
- Protective cover
- Trim piece snap covers
- Documentation
- GMR 18 HD+ radome
- Mounting hardware kit
- Power cable (15 m)
- Network cable (15 m)
- Installation instructions
- Mounting template
Fits:
Compatible Devices
| Product |
|---|
| Compact Reactor™ 40 Hydraulic Autopilot Starter Pack |
| Compact Reactor™ 40 Hydraulic Autopilot with GHC™ 20 and Shadow Drive™ Technology Pack |
| Compact Reactor™ 40 Hydraulic Autopilot with GHC™ 20 Instrument Pack |
| Compact Reactor™ 40 Hydraulic Autopilot with GHC™ 50 and Shadow Drive™ Technology Pack |
| Compact Reactor™ 40 Hydraulic Autopilot with GHC™ 50 Instrument Pack |
| Force® Trolling Motor |
| Garmin AIS™ 300 Blackbox Receiver |
| Garmin AIS™ 600 Blackbox Transceiver |
| Garmin AIS™ 800 Blackbox Transceiver |
| GC™ 10 |
| GC™ 100 Wireless Camera |
| GC™ 12 Marine Camera |
| GC™ 14 Marine Camera |
| GC™ 200 Marine IP Camera |
| GCV™ 10 Scanning Sonar Module |
| GCV™ 20 |
| GLS™ 10 Sonar Module |
| GMI™ 20 |
| GMR™ 1224 xHD2 |
| GMR™ 1226 xHD2 |
| GMR™ 18 HD |
| GMR™ 18 HD+ |
| GMR™ 18 xHD |
| GMR™ 24 HD Radome |
| GMR™ 24 xHD |
| GMR™ 2524 xHD2 |
| GMR™ 2526 xHD2 |
| GMR™ 406 xHD Open Array Radar and Pedestal |
| GMR™ 424 xHD2 |
| GMR™ 606 xHD Open Array Radar and Pedestal |
| GMR™ 624 xHD2 |
| GMR™ 626 xHD2 |
| GMR Fantom™ 124 |
| GMR Fantom™ 126 |
| GMR Fantom™ 18 |
| GMR Fantom™ 254 |
| GMR Fantom™ 256 |
| GMR Fantom™ 4 |
| GMR Fantom™ 54 |
| GMR Fantom™ 56 |
| GMR Fantom™ 6 |
| GNX™ 20 |
| GNX™ 21 |
| GNX™ Wireless Sail Pack 43 |
| GPS 19x HVS (NMEA 0183) |
| GPS 19x NMEA 2000® |
| GPS 24xd |
| GSD™ 24 Advanced Sonar Module |
| GSD™ 25 Premium Sonar Module |
| GSD™ 26 CHIRP Professional Sonar Module |
| gWind™ |
| gWind™ Race |
| gWind™ Wireless 2 |
| GXM™ 53 |
| GXM™ 54 |
| inReach® Mini 2 |
| inReach® Mini 2 Marine Bundle |
| LiveScope™ System |
| Meteor™ 300 Audio System |
| MSC™ 10 Marine Satellite Compass |
| OnDeck™ Hub |
| Panoptix™ PS22-TR |
| Panoptix™ PS30 |
| Panoptix™ PS31 |
| Panoptix™ PS51-TH |
| Panoptix™ PS60 |
| Reactor™ 40 Hydraulic Autopilot |
| Reactor™ 40 Hydraulic Corepack with SmartPump |
| Reactor™ 40 Hydraulic Corepack with SmartPump v2 |
| Reactor™ 40 Kicker Autopilot |
| Reactor™ 40 Mechanical/Retrofit/Solenoid Corepack |
| Reactor™ 40 Steer-by-wire Corepack for Viking® VIPER™ |
| Reactor™ 40 Steer-by-wire Corepack for Volvo Penta® |
| Reactor™ 40 Steer-by-wire Corepack for Yamaha® Helm Master™ |
| Reactor™ 40 Steer-by-wire Standard Corepack |
| VHF 100 Marine Radio |
| VHF 110 Marine Radio |
| VHF 115 Marine Radio |
| VHF 210 AIS Marine Radio |
| VHF 210 Marine Radio |
| VHF 215 Garmin AIS™ Marine Radio |
| VHF 215 Marine Radio |
| VHF 315 Marine Radio |
Product Videos
Custom Field
California Prop 65 Click here for information
Availability Description Item will be ordered direct from the manufacturer and generally ships within 5-10 business days. If ordered with any other item(s), fulfillment will not occur until received.
Ship Method **Special Order Item: Item(s) eligible for FREE shipping, with order value over $99. Orders under $99 incur a $7.99 shipping fee. Faster shipping rates are not available.
Color Black
Available In Stock Quantity 0 Stock On Hand
